Product Summary
The PEX8624-BB50BC F is a 6-port Switch, offers PCI Express switching capability enabling users to add scalable high bandwidth, non-blocking interconnection to a wide variety of applications including workstations, storage systems, and communications platforms. The PEX8624-BB50BC F is well suited for fan-out, aggregation, and peer-to-peer applications.
Features
PEX8624-BB50BC F features: (1)24-lane, 6-port PCIe Gen2 switch, Integrated 5.0 GT/s SerDes; (2)19 x 19mm2, 324-pin FCBGA package; (3)Typical Power: < 4.0 Watts; (4)PCI Express Base Specification, r2.0 (backwards compatible w/ PCIe r1.0a/1.1); (5)PCI Power Management Spec, r1.2; (6)Microsoft Vista Compliant; (7)Supports Access Control Services; (8)Dynamic link-width control; (9)Dynamic SerDes speed control; (10)Non-blocking switch fabric; (11)Full line rate on all ports; (12)Packet Cut-Thru with 145ns max packet latency (x8 to x8); (13)2KB Max Payload Size; (14)Read Pacing (bandwidth throttling); (15)Dual-Cast.
Diagrams
 |
